SecurShield HD Composite RapidLock Polyiso Insulation

SecurShield HD Composite RapidLock Polyiso Insulation

Carlisle's SecurShield HD Composite RapidLock combines the revolutionary membrane attachment method of RapidLock and the incredible performance of SecurShield HD Composite. RapidLock is a hook and loop attachment system powered by VELCRO® Brand Securable Solutions. Carlisle’s insulation boards act as the hook while the FleeceBACK®membranes act as the loop, creating the industry’s first adhesive-less, fully adhered attachment system. RapidLock provides a fully adhered roofing system without VOCs or installation temperature restrictions. Carlisle's SecurShield HD Composite RapidLock Polyiso is a rigid roof insulation panel composed of a top layer of high-density, closed-cell foam, and a bottom layer of 20 psi closed-cell foam. Both layers are laminated to a premium-performance, coated glass mat facer (CGF).

Features and Benefits

SecurShield HD Composite RapidLock is produced on-line, creating a single-component solution that eliminates the need for cover boards, reduces inter-ply adhesives, and saves labor
Allows for adhesive-less roofing system
Superior wind uplift performance: Achieves an FM 1-90 approval rating with only 6 fasteners
Exceptional protection against hail, rooftop traffic, mold, and moisture

Specifikace

Panel Characteristics
- Panel Sizes: 47.5" x 95.5" (1206 mm x 2425 mm) and 47.5" x 47.5" (1206 mm x 1206 mm)
- Panel Thickness: 2.0" to 4.0" in .5" increments
Code and Compliances
- Cover Board – SecurShield HD: ASTM C1289 Type II, Class 4, Grade 1 (109 psi max)
- Base Insulation – SecurShield: ASTM C1289 Type II, Class 2, Grade 2 (20 psi)
- International Building Code (IBC) Chapter 26
- UL Standard 790, 263, and 1256: Component of Class A Roof Systems (refer to UL Roof Materials' System Directory)
- FM Standards 4450/4470: Class 1 approval for steel roof-deck constructions (refer to FM RoofNav)
- Cover Board – SecurShield HD: CAN/ULC S704, Type 3, Class 2
- Base Insulation – SecurShield: CAN/ULC S704 Type 2, Class 2
- Florida Building Code Approval
Carlisle SynTec Systems’ focus has always been innovation – Innovation to solve problems, improve performance, reduce labor, and above all, improve sustainability. Carlisle is committed to driving sustainable and efficient processes in the design and manufacturing of our products.
- Highest R-value per inch providing maximum energy savings and CO2emissions avoidance
- PIMA Quality MarkCM Certification Program participant for Long-Term Thermal R-values (LTTR)
- Carlisle Polyiso Roof Insulation and HD Cover Board EPDs available
- Contributes to LEED® and Green Globes certification requirements
- End-of-life jobsite disposal options are available for reuse/repurposing
- HFC- and HCFC-free formulation

Technická specifikace

Jedinečná ref. hodnotasecurshield-hd-composite-rapidlock-polyiso-insulation
Skupina výrobkůRoofing-Products
Skupina produktůInsulation
TypObjekt
Datum zveřejnění2026-08-27
Číslo vydání1

Odkazy

Související

Hlavní materiálPolyisokyanurát PIR

Klasifikace

Kategorie objektu BIMStavební materiály - Izolace
Klasifikace IFCStřecha
Kód ETIMEC000406
Název ETIMThermal insulation
Kód Uniclass 2015Pr_25_31_28_65
Popis Uniclass 2015Polyisocyanurate (PIR) foam insulation
Kód CSI MasterFormat 201407 21 13.13
Název CSI MasterFormat 2014Foam Board Insulation
Číslo OmniClass23-13 25 19 11
Název OmniClassSlab and Board Thermal Insulation
