Vernis Blend Electronic basin mixer with temperature pre-adjustment mains connection 230 V
hansgrohe
Archivovány

Vernis Blend Electronic basin mixer with temperature pre-adjustment mains connection 230 V

Vernis Blend Electronic basin mixer with temperature pre-adjustment mains connection 230 V
Specifikace
  • Surfaces: - 71501000 Chrome Specification: • ComfortZone 100 • projection 112 mm • spray type: normal spray • swiveling spray former • maximum flow rate at 3 bar: 5 l/min • temperature pre-adjustable • with isolated water conduction - without contact with nickel and lead • non-return valve • infrared sensor technology • automatic environmental adjustment of infrared sensor • 230 V / 50 Hz mains connection • running time adjustable • running time: 10 s, 20 s, 30 s • hygiene rinse activatable (automatic water flow) • frequency of hygiene rinse: 24 h, 48 h, 72 h • flushing time hygiene rinse: 10 s, 20 s, 30 s • permanent rinse activatable (single water flow for 200 seconds, suitable for thermal disinfection) • cleaning mode: manual water stop for washbasin cleaning • connection dimension: DN15 • dirt filters in the connection hoses • frequency of hygiene rinse and flushing time hygiene rinse are dependent on each other (24 h - 10 s, 48 h - 20 s, 72 h - 30 s)
Technická specifikace
  • Jedinečná ref. hodnota71501000
  • Skupina výrobkůElectronic mixers
  • Skupina produktůVernis Blend
  • TypObjekt
  • Číslo vydání1
  • Výška (mm)122
  • Šířka (mm)57
  • Hloubka (mm)158
Související
  • Hlavní materiálChrom
  • Vedlejší materiálChrom
  • Navrženo vNěmecko
  • Vyrobeno vNěmecko
  • Čistá hmotnost (kg)1.3
Klasifikace
  • Kategorie objektu BIMSanita - Vodovodní baterie
  • Klasifikace IFCSvorkovnice pro sanitu
  • Kód ETIMEC010340
  • Název ETIMElectronic tap
  • Název UNSPSCSanitary ware
  • Kód UNSPSC301815
  • Kód Uniclass 2015Pr_60_75_08_54
  • Popis Uniclass 2015Mixers
  • Kód CSI MasterFormat 201441 14 33
  • Název CSI MasterFormat 2014Mixers
  • Číslo OmniClass23-31 11 00
  • Název OmniClassFaucets
  • Kód CSI UniFormat IID2010
  • Název CSI UniFormat IIPlumbing Fixtures
