Aragon Fit

PRO-LEVEL EFFICIENCY, QUALITY AND INTELLIGENCE

The new level for weather-proof luminaires: Aragon Pro LED combines the highest quality of light and efficiency, and can be perfectly adapted to on-site requirements thanks to its modular design. To achieve minimum energy consumption and maximum convenience the luminaires can be quickly and easily networked, either via DALI or radio.

Specifikation

TECHNISCHE FEATURES

Energy efficiency	up to 180 lm/W
Lumen packages	2.300 lm - 13.000 lm
Service life	HE: L80 100.000 h tq 25°C L80 70.000 h tq 25°C Special LT/HT variants: -40° to +50°
Colour rendering / colour temperatures	Ra > 80/ Ra> 90 4.000 K 6.500 K HCL: optional
Light distribution	P-W (wide distribution), P-N (narrow distribution), P-VW (very wide distribution), P-XW (extremely wide distribution), P-AW (asymmetric distribution)
Electrical version	ET, ETDD, Mulitlumen, CLO optional
Protection rating / safety class	IP 66 PMMA: IK03 PC: IK08 CR (Polyamid): IK07
Sensor technology	HFS, HFSB / HFSX
Control	Swarm intelligence LiveLink: control, monitoring + Special LiveLink Wi-Fi radio refurbishment solution
Luminaire colour	Light grey, similar to RAL 7035 / translucent

Teknisk specifikation

Unik ref.Aragon_Fit
ProduktfamilieIndoor lighting
ProduktgruppeLuminaires with higher degree of protection
TypeObjekt (enkelt objekt)
Udgivelsesdato2023-11-23
Udgavenummer1

Links

Produkt-URLhttp://www.trilux.com/aragonfit/

Relateret

Designet iTyskland
Fremstillet iTyskland

Klassifikation

BIMobject-kategoriBelysning - Loftsmonteret
IFC-klassifikationBelysningsarmatur
ETIM-kodeEC002892
ETIM-navnCeiling-/wall luminaire
