URSA Mineral wool URSACOUSTIC BE

URSA Mineral wool URSACOUSTIC BE

URSA TERRA, the new generation mineral wool combines strong thermal, acoustic and fire performance with top indoor air quality levels. URSA TERRA is also less dusty & has a softer touch.

Specification

URSACOUSTIC N (λ37) is a naked mineral wool slab suitable for thermal & acoustic insulation of walls & facades. The panel has the following characteristics: thickness 100 mm; length 1.350 mm; width 600 mm thermal resistance R=1.05 [m2K/W] -thickness 40[mm]; thermal resistance R=1.20 [m2K/W] -thickness 45[mm]; thermal resistance R=1.35 [m2K/W] -thickness 50[mm]; thermal resistance R=1.60 [m2K/W] -thickness 60[mm];thermal resistance R=2.00 [m2K/W] -thickness 75[mm]; thermal resistance R=2.70[m2K/W] -thickness 100[mm]; thermal resistance R=3.20 [m2K/W] -thickness 120[mm]; thermal resistance R=4.05 [m2K/W] -thickness 150[mm];

Technical specification

Unique ref.BE_MAT_GLW_TER_Ursacoustic_N_37_100_1
Product familyURSA TERRA
Product groupInsulation
TypeBuilding Material
Date of publishing2019-10-30
Edition number1
Height (mm)1000
Width (mm)1000
Depth (mm)100

Links

Product urlhttp://www.ursa.be/
Product certificationhttp://www.ursa.be/
Technical descriptionhttp://www.ursa.be/

Related

Material mainMineral wool
Designed inBelgium
Manufactured inBelgium
Weight Net (Kg)1.7

Classification

BIMobject CategoryBuilding Materials - Insulation
IFC classificationMaterial
UNSPSC nameInsulation
UNSPSC code3014
Uniclass 2015 CodePr_25_57_06_53
Uniclass 2015 DescriptionMineral wool insulation
CSI MasterFormat 2014 Code07 21 00
CSI MasterFormat 2014 TitleThermal Insulation
OmniClass Number23-13 25 19 11 17
OmniClass TitleFiberglass Slab and Board Thermal Insulation

Region availability

Europe
Belgium
