FlowCalPLUS™ Compact Automatic Flow Balancing Valve with Inlet Check Valve - NA Market
Caleffi

FlowCalPLUS™ Compact Automatic Flow Balancing Valve with Inlet Check Valve - NA Market

The FlowCalplus compact dynamic flow balancing valve is pressure independent and maintains a fixed flow rate as differential pressures vary. It incorporates an exclusive flow cartridge, made of an anti-scale, low noise polymer. Constructed of DZR low-lead brass, FlowCalplus is ideally suited for use in plumbing applications such as hot water recirculation systems. The built-in check valve protects against circuit thermo-siphoning. The outlet temperature gauge (optional) verifies the fluid temperature in the circuit. The FlowCalplus can also be used in hydronic systems.
The FlowCal+ balancing valve is available with NPT male, sweat, press, PEX crimp and PEX expansion union connections. The union nut makes installation and maintenance fast, easy and efficient for a variety of tailpiece options.

Caleffi code 290030 full-port ball valve is designed for isolating the FlowCalplus 127AFC series. The isolation valve installs in between the valve body and the tailpiece fitting assembly. Male x Female configuration and bi-directional full ball valve flow capacity provides flexibility for using one or two isolation valves for the primary functioning valve. An optional stem extension is also available for those projects that require pipe insulation.

Visit bim.caleffi.com to stay updated.
      290030 isolation ball valve and stem extension can be selected in the Revit file for inlet and/or outlet ports.

Specification
  • 29Compact automatic flow balancing valve for domestic hot water recirculation systems.

    DZR low-lead brass valve body.

    Patented, anti-scale, low noise polymer FlowCalplus cartridge.

    Inlet flow check valve.

    Max working pressure: 230 psi (16 bar)

    Temp range: 32 deg F - 212 deg F (0 deg C – 100 deg C)

    Differential pressure control ranges: 2 - 14, 2 - 32, 4 - 34 and 5 - 35 psid

    Flow rate: 16 fixed flow rate settings ranging from 0.5 - 10.0 GPM

    Flow accuracy: plus or minus 10 per cent

    With optional temperature gauge:

    Diameter: 2 inch

    Gauge dual-scale: 30 deg F - 210 deg F (0 deg C - 100 deg C)

    Gauge accuracy: plus or minus 6 deg F

    U.S. Patent 7,246,635 B2.

    Compliance with the following standards:

    NSF/ANSI/CAN 372 - Drinking Water System Components - Lead Content

    Reduction of Lead in Drinking Water Act - California Health and

    Safety Code 116875

    S.3874 - Reduction of Lead in Drinking Water Act

    Vermont Act 193 - The Lead in Plumbing Supplies Law

    Maryland's Lead Free Law Hb.372

Technical specification
  • Unique ref.127AFC
  • Collection setPLUMBING
  • CollectionNorth America
  • TypeObject (single object)
  • Date of publishing2020-08-05
  • Edition number2
Related
  • Material mainBrass
  • Material secondaryPolymer
Classification
  • BIMobject CategoryPlumbing - Valves
  • IFC classificationValve
  • UNSPSC nameValves
  • UNSPSC code401416
  • Uniclass 2015 CodeSs_40_15_75
  • Uniclass 2015 DescriptionSanitary appliance systems
  • CSI MasterFormat 2014 Code22 00 00
  • CSI MasterFormat 2014 TitlePlumbing
  • OmniClass TitleBalancing Valves
  • OmniClass Number23-27 31 13
  • CSI UniFormat II CodeD20
  • CSI UniFormat II TitlePLUMBING

Region availability

North America
Canada
United States
