Z-One: 2-way Zone Valves Normally Closed- Press – NA Market

Two-way zone valve with Presscon™ fitting Spring return. Normally closed actuator. Auxiliary micro-switch. Overall length: 5⅝" Lay length: 3¾" Max body pressure: 300 psi Temp range: 32˚ - 240˚F Suitable fluids: water, 50% max glycol, 15 psi max steam Power Supply: 24 VAC Power Consumption: 5 W, 7 VA Rating of auxiliary micro switch contacts: 0.0 A min, 0.4 A max 24 V (24 V only) UL 873, cUL Listed and CE. UL 1995 Sec. 18 air plenums and ducts. US Patent 7,048,251. Install the Z-one™ valves together with our ZVR relay and qualify for an industry exclusive five year warranty. Visit bim.caleffi.com to stay updated.
Specification
  • Z-one™ valves are used to automatically shut-off the flow or redirect hot and chilled water in hydronic systems, open systems, closed systems, low-pressure steam; and are UL listed for plenum installations. The motorized two-position, on/off, spring return Z1 series actuator has an end mounted push button for quick installation to the valve body. The actuator is equipped with or without an auxiliary micro-switch and models are either normally closed or normally open and with wire or terminal connections. The high temperature zone valve body Z2 series is 2-way straight through and the valve body Z3 series is 3-way diverting or mixing. The Z1 series actuator is easily attached by a push button lock and requires no tools. The Z-one valve provides 100% bubble-tight seat close-off leakage. The high temperature and high close-off performance characteristics of these zone valves, combined with the compact size, makes them suitable to fit inside baseboards or directly in fan coil units. Z-one valves are available with ½ to 1 inch press fittings, a copper tail-piece with union nut, making installation and maintenance fast, easy and efficient. Special slots in the EPDM O-ring allows fluid to leak during system testing if unpressed and provide a perfect leak proof seal when completely pressed. Some models are low-lead brass, for domestic hot water applications.
Technical specification
  • Unique ref.Z4_Z5_Press
  • Product familyHVAC
  • Product groupNorth America
  • TypeObject (single object)
  • Date of publishing2020-08-05
  • Edition number1
Related
  • Material mainBrass
  • Material secondaryStainless steel
  • Designed inItaly
  • Manufactured inItaly
Classification
  • BIMobject CategoryHVAC - HVAC
  • UNSPSC nameValves
  • UNSPSC code401416
  • Uniclass 2015 CodeSs_60
  • Uniclass 2015 DescriptionHeating, cooling and refrigeration systems
  • CSI MasterFormat 2014 Code23 00 00
  • CSI MasterFormat 2014 TitleHeating, Ventilating, and Air Conditioning (HVAC)
  • OmniClass Number23-27 31 00
  • OmniClass TitleValves
  • CSI UniFormat II CodeD30
  • CSI UniFormat II TitleHVAC

Region availability

North America
Canada
United States
