C221 Two-Way ScreenArray® Cinema Loudspeaker

Unique ref.: C221-Two-Way-ScreenArray-Cinema-Loudspeaker
Brand: JBL Professional
Product family: Cinema Sound
Product group: Small Format
Date of publishing: 2019-06-22
Edition number: 1
Type: Object (single object)
Download (10)

Two-Way ScreenArray Cinema Loudspeaker

The C221 Two-Way ScreenArray® Cinema Loudspeaker combines JBL’s latest technological advances with a compact footprint and accessible price point, making it easy to upgrade the sonic experience in your small or mid-sized cinema. Featuring patent-pending Dual Dissimilar Arraying and Acoustic Aperture Technology, the C221 provides remarkably uniform coverage and smooth, accurate sound reproduction for every member of your audience. The C221 has a depth of 12”, making it perfect for small and medium multiplexes with space constraints. And since the C221 uses the same driver technology trusted by top movie studios around the world, your audience will enjoy a more captivating, authentic experience from every seat in the house—just like the creators intended

FEATURES

  • Next-generation two-way ScreenArray® design for maximum output, improved coverage and minimum distortion
  • Patent-pending Dual Dissimilar Arraying Technology creates coverage pattern for raked seating areas, and extends HF output power and pattern control a full octave in both spectrum extremes
  • Patent-pending Acoustic Aperture Technology delivers improved drivers for lower distortion and higher sensitivity, plus enhanced mid-range performance for a smooth crossover transition
  • 12" footprint saves space without sacrificing performance
  • Designed for small and medium sized cinemas with a maximum throw distance of 15m (49.20ft)

Keywords: Harman

SPECIFICATIONS

Frequency Response (-3dB) 77Hz - 18kHz
Frequency Response (-6dB) 58kHz - 20kHz
Frequency Response (-10dB) 44Hz - 20kHz
Crossover Frequencies 1700Hz (LF), 2000Hz (HF1), 1700Hz (HF2)
Free Field Passive Sensitivity 100dB SPL @2.83V
Calculated Max SPL 125 dB
Passive Rated Impedance 8Ω
Minimum Impedance 7Ω @ 167Hz
Power Handling (2Hr AES Rating) 300W
Power Handling (100Hr AES Rating) 150W
LF Sensitivity 100dB SPL @ 2.83V
HF Sensitivity 100 dB SPL @ 2.83V
Furthest Seat 15m/49.20ft
Unit Weight (lbs) 100
Unit Weight (kg) 45.36
Dimensions (H x W x D) Inches 35" x 34" x 12"
Dimensions (H x W x D) Centimeters 88.9 x 85.73 x 30.48


Material main:
Material secondary:
Designed in: United States
Manufactured in: United States

BIMobject Category: Electronics - Audio Electronics
IFC classification: Object
UNSPSC name: Audio and visual presentation and composing equipment
UNSPSC code: 4511
Uniclass 1.4 Code: L76116
Uniclass 1.4 Description: Loudspeakers
Uniclass 2.0 Code: PR-75-06-49
Uniclass 2.0 Description: Loudspeakers
Uniclass 2015 Code: Pr_70_75_36_50
Uniclass 2015 Description: Loudspeakers
NBS Reference Code: 75-06-49
NBS Reference Description: Loudspeakers
CSI MasterFormat 2014 Code: 11 52 00
CSI MasterFormat 2014 Title: Audio-Visual Equipment
OmniClass Number: 23-37 15 29 11 13
OmniClass Title: Loudspeakers
