VRX915S - Available in White 15 in. Bass Reflex Subwoofer

Unique ref.: VRX915S-15-Bass-Reflex-Subwoofer
Brand: JBL Professional
Product family: Installed Sound
Product group: Line Array Speakers
Date of publishing: 2019-06-22
Edition number: 1
Type: Object (single object)
Download (8)

15 in. Bass Reflex Subwoofer
The VRX915S is a compact, high power suspendable subwoofer system containing a 2265G-1 neodymium magnet, patented Differential Drive®, 15" woofer in a front-loaded, vented enclosure.

FEATURES

  • Integral rigging hardware for simple connection of VRX915S line-arrays and optional array frame.
  • 15 inch, 2265G-1 Differential Drive® woofer for extended low-frequency output.
  • Light and compact for versatility and easy handleability.
  • 20 mm threaded pole socket for solid, secure satellite speaker mounting.

APPLICATIONS

  • Live performance systems.
  • Mobile and fixed DJ systems.
  • Sound system rental and tour.
  • Permanent installations.

Keywords: Harman

SPECIFICATIONS
Power Rating 800 W / 1600 W / 3200 W
Frequency Range 35 Hz - 250 Hz (-10 dB)
Dimensions
(H x W x D) 496 mm x 420 mm x 597 mm
(19.5 in x 16.5 in x 23.5 in)
Frequency Response 40 Hz - 250 Hz (+/-3db)
System Maximum SPL 126 dB SPL
System Sensitivity (1w @ 1m 91 dB SPL
LF Driver 1 x JBL 2265G-1, 250 mm (15 in) Differential Drive® woofer
Nominal Impedance 4 Ohms
Enclosure 15 mm - 18 mm, multi ply birch plywood
Suspension / Mounting Top mounted M20 threaded socket for optional pole SS4-BK. Integrated flying hardware for use with array frame VRX-SMAF. 8 M10 fittings. Optional M10 eyebolt kit.
Finish Black DuraFlex™ finish
Grille Power coated, black, 16-gauge perforated steel with acoustically transparent black foam backing.
Input Connectors Switchable, +1/-1 or +2/-2
Net Weight 26.3 kg (58 lb)


Material main:
Material secondary:
Designed in: United States
Manufactured in: United States

BIMobject Category: Electronics - Audio Electronics
IFC classification: Object
UNSPSC name: Audio and visual presentation and composing equipment
UNSPSC code: 4511
Uniclass 1.4 Code: L76116
Uniclass 1.4 Description: Loudspeakers
Uniclass 2.0 Code: PR-75-06-49
Uniclass 2.0 Description: Loudspeakers
Uniclass 2015 Code: Pr_70_75_36_50
Uniclass 2015 Description: Loudspeakers
NBS Reference Code: 75-06-49
NBS Reference Description: Loudspeakers
CSI MasterFormat 2014 Code: 11 52 00
CSI MasterFormat 2014 Title: Audio-Visual Equipment
OmniClass Number: 23-37 15 29 11 13
OmniClass Title: Loudspeakers
This product is available in:
North America
  • Anguilla
  • Antigua and Barbuda
  • Aruba
  • Barbados
  • Belize
  • Bermuda
  • British Virgin Islands
  • Canada
  • Caribbean Netherlands
  • Cayman Islands
  • Collectivity of Saint Martin
  • Costa Rica
  • Cuba
  • Curaçao
  • Dominica
  • Dominican Republic
  • El Salvador
  • Greenland
  • Grenada
  • Guadeloupe
  • Guatemala
  • Haiti
  • Honduras
  • Jamaica
  • Martinique
  • Mexico
  • Montserrat
  • Nicaragua
  • Panama
  • Puerto Rico
  • Saint Kitts and Nevis
  • Saint Lucia
  • Saint Pierre and Miquelon
  • Saint Vincent and the Grenadines
  • Saint-Barthélemy
  • Sint Maarten
  • The Bahamas
  • Trinidad and Tobago
  • Turks and Caicos Islands
  • U.S. Virgin Islands
  • United States

BIMobject SEEK Properties

Electronics - Audio

Name Value
Depth 597 mm
Height 496 mm
Width 420 mm
