VM BUILDING SOLUTIONS

FR_VMBSO_Membrane roofing_Hertalan EPDM

Hertalan is an unreinforced EPDM membrane. Mid-range.

Root-resistant: Hertalan is FLL-certified for 1.5 mm and 2 mm thicknesses with factory-vulcanized seams.

Associated products:

- Hertalan Flashing – Self-adhesive, moldable, non-vulcanized EPDM strip for finishing details.

- Hertalan Prefabricated Inside and Outside Corners.

- KS 137, KS 143, KS 205, and KS 96 Adhesives

Specification

Thickness: 1,2 & 1,5 mm & 2 mm
Widths: 1,4m_2,8m & 3,5m and other options
Lengths: 20m, 30m & 25m and other options
Weight: 1,47 kg/m² (1,2mm) - 1,84 kg/m² (1,5mm) - 2,46 kg/m² (2,0mm)
Types of roofs
New & renovation, Accessible, technical or non-accessible roof
Document of reference: Technical Assessment (DTA) N°5.2/17-2578_V2, DTU 43 Series, Hertalan Standard Specifications (CCT) approved by Alpha Contrôle – April 2017
Support:
Masonry, Autoclaved Aerated Concrete (AAC), Wood and wood-based products, Insulation (weldable mineral wool, weldable expanded perlite, cellular glass, PIR, PUR, polystyrene…), Existing bituminous membranes

Technical specification

Unique ref.FR_HERTALAN_EPDM
Product familyROOF INSULATION
Product groupEPDM Collection
TypeAssembly (multiple objects)
Date of publishing2026-10-01
Edition number1
Height (mm)30500
Width (mm)3050
Depth (mm)1.5

Links

Related

Designed inFrance
Manufactured inUnited States

Classification

BIMobject CategoryConstruction Materials - Waterproofing & Membranes
IFC classificationRoof
UNSPSC nameRoofing membranes
UNSPSC code30151505
Uniclass 2015 CodePr_25_57_51_27
Uniclass 2015 DescriptionEthylene propylene diene monomer (EPDM) geomembranes
CSI MasterFormat 2014 Code07 50 00
CSI MasterFormat 2014 TitleMembrane Roofing
OmniClass Number23-13 39 31
OmniClass TitleRoof Membranes
CSI UniFormat II CodeB3010
CSI UniFormat II TitleRoof Coverings

Region availability

Europe
France
