AXOR ShowerSolution 250/250 1jet ceiling conc.chrom

Specification

Specification

• Surfaces: - 35309000 Chrome - 35309020 Polished Chrome - 35309130 Polished Bronze - 35309140 Brushed Bronze - 35309250 Brushed Gold Optic - 35309260 Brushed Chrome - 35309300 Polished Red Gold - 35309310 Brushed Red Gold - 35309330 Polished Black Chrome - 35309340 Brushed Black Chrome - 35309350 Satin Black - 35309800 Stainless Steel Optic - 35309820 Brushed Nickel - 35309830 Polished Nickel - 35309930 Polished Brass - 35309950 Brushed Brass - 35309990 Polished Gold Optic Specification: • shower head size: 250 x 250 mm • spray type: PowderRain • dynamic spray nozzles move out while using • material spray disc: metal • maximum flow rate at 3 bar: 18,1 l/min • flow rate PowderRain spray (at 3 bar): 18,1 l/min • function from: 15,4 l/min • minimum flow pressure: 1,8 bar • overhead shower removable for cleaning • installation: flush with the ceiling • connection dimension: DN15 • suitable for continous flow water heaters

Technical specification

Technical specification

• Unique ref.35309000
• Product familyAXOR ShowerSolutions
• Product groupOverhead showers
• TypeObject (single object)
• Date of publishing2019-04-01
• Edition number1
• Height (mm)71
• Width (mm)250
• Depth (mm)250

Links

Links

• Product urlhttps://www.axor-design.com/articledetail--35309000
• Technical descriptionhttps://www.axor-design.com/de-de/articledetail--35309000.html

Related

Related

• Designed inGermany
• Manufactured inGermany
• Weight Net (Kg)5.1

Classification

Classification

• BIMobject CategorySanitary - Showers
• IFC classificationSanitary Terminal
• ETIM CodeEC011383
• ETIM NameShower head
• UNSPSC nameShowers
• UNSPSC code30181503
• Uniclass 2015 CodePr_40_20_87_76
• Uniclass 2015 DescriptionShower heads
• CSI MasterFormat 2014 Code22 41 23
• CSI MasterFormat 2014 TitleResidential Showers
• OmniClass Number23-31 17 00
• OmniClass TitleShowers
• CSI UniFormat II CodeD2010
• CSI UniFormat II TitlePlumbing Fixtures
