LVRCDWSPRO Elkay® Pro Filtration™ VR Bottle Filling Station & Single ADA Cooler w/ Ultra Capacity Lead Filter - SS
LVRCDWSPRO Elkay® Pro Filtration™ VR Bottle Filling Station & Single ADA Cooler w/ Ultra Capacity Lead Filter - SS
LVRCDWSPRO Elkay® Pro Filtration™ VR Bottle Filling Station & Single ADA Cooler w/ Ultra Capacity Lead Filter - SS
LVRCDWSPRO Elkay® Pro Filtration™ VR Bottle Filling Station & Single ADA Cooler w/ Ultra Capacity Lead Filter - SS
LVRCDWSPRO Elkay® Pro Filtration™ VR Bottle Filling Station & Single ADA Cooler w/ Ultra Capacity Lead Filter - SS
    Elkay

    LVRCDWSPRO Elkay® Pro Filtration™ VR Bottle Filling Station & Single ADA Cooler w/ Ultra Capacity Lead Filter - SS

    Ultra Capacity Lead Filter - SS. Features shall include Alcove Light, Automatic Filter Flush, Automatic Filter Status Reset, Energy Savings, Filtered, Green Ticker™, Hands Free, Laminar Flow, Pro Filtration System, Real Drain, Stainless Steel Alcove, Top Mount Quick Filter Change, Visual Filter Monitor, Cloud Connected Device, Vandal Resistant, Tempered Glass Display Cover. Furnished with Vandal Resistant bubbler. Electronic Bottle Filler Sensor with Mechanical Front Bubbler Button activation. Product shall be Wall Mount (On Wall), for Indoor applications, serving 1 station(s). Unit shall be certified to UL 399 and CAN/CSA C22.2 No. 120.

    Features:

    • 10,000-gallon ultra filter capacity helps extend uptime and reduce maintenance frequency— ideal for high-traffic environments
    • Certified Filtration: Certified by IAPMO R&T to NSF/ANSI 42, 53 and 401 to reduce lead, microplastics, cysts, asbestos, turbidity, particulate class 1, chlorine, and taste and odor, and to NSF/ANSI/CAN 372 for lead free compliance. FLP4 Filter also available for *Total PFAS reduction (*Total PFAS as defined by NSF/ANSI 53)
    • Top-Access Filter Replacement: Change filters in seconds from the top- minimizing maintenance time and system disruption
    • High-Capacity Filtration: Delivers filter life capacity that exceeds industry standards, with options up to 20,000 gallons- extending uptime and reducing filter changeouts
    • Vandal-Resistant Stainless Steel Design: Durable construction engineered for high-traffic environments with a sleek, modern aesthetic
    • Smart Connected: Remotely track filter status, anticipate maintenance, flush the unit, and monitor bottles saved for sustainability insights
    • Filter Life Monitoring: Blue LCD display shows remaining filter capacity at a glance- helping teams stay ahead of maintenance and avoid unplanned downtime
    Specification
    • keywords: Profiltration, Pro-Filtration, Pro Filtration ezh20, bottle filler, next gen, lead reduction, reduces lead, reduce lead, take out lead, no lead, low lead, leadfree, NSF, NSF372, NSF 372, EZH20

    Technical specification
    • Unique ref.LVRCDWSPRO
    • Product familyBOTTLE FILLING STATION
    • Product groupezH2O Liv Pro
    • TypeObject (single object)
    • Date of publishing2026-09-21
    • Edition number1
    Related
    • Material mainStainless steel
    • Designed inUnited States
    Classification
    • BIMobject CategorySanitary - Drinking fountains
