Raindance S Overhead shower 240 1jet 2.5 GPM

Raindance S Overhead shower 240 1jet 2.5 GPM
Specification
  • Surfaces: - 27474001 Chrome - 27474821 Brushed Nickel - 27474931 Polished Brass Specification: • shower head size: 240 mm • spray type: RainAir • ball-joint: overhead shower angle adjustable • material spray disc: metal • fully finished matching spray face • maximum flow rate at 3 bar: 9,5 l/min • installation: ceiling or wall • connection thread NPT ½ • suitable for continous flow water heaters
Technical specification
  • Unique ref.27474001
  • Collection setRaindance S
  • CollectionOverhead showers
  • TypeObject (single object)
  • Date of publishing2022-11-23
  • Edition number1
  • Height (inches)2.13
  • Width (inches)9.36
  • Depth (inches)9.36
Related
  • Designed inGermany
  • Manufactured inGermany
  • Weight Net (Lbs)2.1
Classification
  • BIMobject CategorySanitary - Showers
  • IFC classificationSanitary Terminal
  • UNSPSC nameShowers
  • UNSPSC code30181503
  • Uniclass 2015 CodePr_40_20_87_76
  • Uniclass 2015 DescriptionShower heads
  • CSI MasterFormat 2014 Code22 41 23
  • CSI MasterFormat 2014 TitleResidential Showers
  • OmniClass TitleShowers
  • OmniClass Number23-31 17 00
  • CSI UniFormat II CodeD2010
  • CSI UniFormat II TitlePlumbing Fixtures

Region availability

North America
United States
