Control 416C/T 6.5" Two-Way Coaxial Ceiling Loudspeaker

Control 416C/T 6.5" Two-Way Coaxial Ceiling Loudspeaker

The JBL Control 416C/T, part of the Control 400 Standard Coverage Series, is a two-way coaxial ceiling loudspeaker, featuring a 6.5” woofer and an integrated enclosure that is ideal for installation in most ceiling plenum spaces.

All Control 400 Series models are designed to blend seamlessly into modern interiors. The included full-face magnetic grille is paintable for integration into any decor, while available black round and white square grilles provide added customization.

The Control 416C/T includes thoughtfully engineered installation features to enhance safety, efficiency, and repeatability. The terminal cover allows for convenient top or side cable entry and the reliable captive dogear design accommodates a variety of ceiling thicknesses, ensuring versatility for any environment. Additionally, the Control 416C/T supports both 70V/100V and low impedance applications.

Features

165 mm (6.5 in) woofer and 20mm (0.75 in) soft-dome tweeter
Integrated enclosure that is ideal for installation in most ceiling plenum spaces
Built-in 70V/100V multi-tap transformer, plus 8-ohm direct input
Full-face, easily paintable magnetic grilles
Top and side cable entry options
Robust and adaptable dogears for wide range of ceiling thicknesses
IP33 rated

Specification

Frequency Range (-10 dB)	61Hz - 20kHz
Power Capacity	75W (300W Peak) Cont. Pink Noise (2 hrs) 50W (200W Peak) Cont. Pink Noise (100 hrs)
Sensitivity (1m/1W)	89dB
Coverage Angle	120° conical
Maximum SPL (1m)	108 dB continuous pink noise (114 dB peak)
Nominal Impedance	8Ω
Transformer Taps	70 V: 30 W, 15 W, 7.5 W & 3.8 W 100 V: 30 W, 15 W, 7.5 W
Drivers	LF: 165 mm (6.5 in) with paper cone, SBR surround. HF: 20 mm (0.75 in) soft dome
Ceiling Cutout Size	223 mm (8.8 in)
Dimensions	233 mm (9.3 in) H x 261 mm (10.4 in) dia. 222 mm (8.9 in) from bottom of ceiling tile to top of backcan
Safety Agency Rating	Suitable for use in air handling spaces per UL 2043, NFPA 90A & NFPA 70, CSA C22.2 no. 205 listed. Listing per UL 1480A Speakers for Commercial and Professional Use. UL registered Transformer.
Environmental	IP rating: IP33 per EN/IEC 60529. Operating temperature: 0° C to 45 °C.
Optional Accessories	JBL-MTC-416BG black (RAL9004) round grille JBL-MTC-416SG white (RAL9003) square grille JBL-MTC-416WG weather grille JBL-MTC-426NC new construction bracket JBL-MTC-426MR mud-ring construction bracket JBL-MTC-48TRX4 tile rail for 4' x 4' ceiling tiles
Color	Stock grille is White (RAL9003), paintable
Net Weight (ea)	3.75 kg (8.27 lbs)
Shipping Weight (pair)	12.64 kg (27.87 lbs)
SKU Numbers	JBL-C416C/T

Technical specification

Unique ref.control-416c-t-65-two-way-coaxial-ceiling-loudspeaker
Product familyInstalled Sound
Product groupCeiling Speakers
TypeObject (single object)
Date of publishing2025-11-04
Edition number1

Links

Product urlhttps://jblpro.com/en-US/products/control-416c-t
Installation instructionshttps://jblpro.com/en-US/products/control-416c-t#downloads
Product certificationhttps://jblpro.com/en-US/products/control-416c-t
Technical descriptionhttps://jblpro.com/en-US/site_elements/control-416c-t-spec-sheet

Designed inUnited States
Manufactured inUnited States

Classification

BIMobject CategoryElectronics - Audio
IFC classificationObject
ETIM CodeEC000682
ETIM NameLoudspeaker set
Uniclass 2015 CodePr_70_75_36_50
Uniclass 2015 DescriptionLoudspeakers
CSI MasterFormat 2014 Code11 52 00
CSI MasterFormat 2014 TitleAudio-Visual Equipment
OmniClass Number23-37 15 29 11 13
OmniClass TitleLoudspeakers
