Drinking water tank internal waterproofing - MasterSeal 6808

MasterSeal M 808 is a multi-purpose waterproofing membrane for water management industry both for areas with high chemical and mechanical demands (inflow) and for areas where potable water is stored (disinfection and outflow). Additionally it is used in industrial process areas where concrete or steel structures are affected by water containing dissolved aggressive chemicals. The system comprises: Primer: MasterSeal P770. Special primer for MasterSeal M membranes applied on mineral (dry or humid) substrates. Alternative Primer: MasterSeal P 385 Epoxy-cement primer for the application of membranes on humid mineral absorbent and non absorbent substrates. Membrane: MasterSeal M 808 Two component elastic polyurethane membrane with high chemical resistance.

Specification

Application of 2 (3) coats with minimum total approximate thickness of 0,5 (0,8) mm of two-component, 100% solid content, polyurethane waterproof coating approved under regulation 31 of the Water Supply (Water Quality) regulations 2000 for use in contact with potable water, MasterSeal M 808 from Master Builders Solutions (or similar / analogous). The membrane will be applied on suitable primer according producer's instructions. Physical properties of the product: Water vapour permeability (EN ISO 7783-1,2): Sd ≤ 7 m (0,5 mm thickness) CO2 permeability (EN 1062 – 6): Sd ≥ 50 m (0,5 mm thickness) Capillary water absorption (EN 1062-3): w ≤ 0,01 kg/m2 h0.5 Crack bridging (static EN 1062 – 7 (A)): ≥ A4 (23ºC); ≥ A3 (-10ºC); ≥ A2 (-20ºC) Crack bridging (dynamic EN 1062 - 7 (B)): ≥ B2 (20ºC, -20ºC) Adhesion to concrete (EN 1542): ≥ 3,0 N/mm2 Adhesion to concrete after freeze-thaw cycling (EN 13687-1): ≥ 2,5 N/mm2 Impact resistance (EN ISO 6272): ≥ 20 Nm Abrasion resistance (EN ISO 5470-1): ≤ 350 mg

Technical specification

Unique ref.MasterSeal_6808
Product familyMasterSeal® - Master Builders Solutions
Product groupDrinking Water and Foodstuff Waterproofing Coatings
TypeObject (single object)
Date of publishing2018-03-27
Edition number1

Links

Product urlhttps://www.master-builders-solutions.com/en-gb/products/masterseal/masterseal-m-808-waterproofing-membrane?Product=MasterSealM808
Installation instructionshttps://assets.master-builders-solutions.com/en-gb/masterseal-m808-tds.pdf
Instruction videohttps://www.youtube.com/channel/UCmliX4XCw0M_G4GUjNumU3w
Product certificationhttps://assets.master-builders-solutions.com/en-gb/dop_masterseal_m_808_eng.pdf
Technical descriptionhttps://assets.master-builders-solutions.com/en-gb/masterseal-m808-tds.pdf

Material mainPolyurethane

Classification

BIMobject CategoryBuilding Materials - Waterproofing & Membranes
IFC classificationMaterial
Uniclass 2015 CodePr_35_31_68_64
Uniclass 2015 DescriptionPolyurethane (PUR) waterproof coatings
CSI MasterFormat 2014 Code07 14 00
CSI MasterFormat 2014 TitleFluid-Applied Waterproofing
OmniClass Number23-13 25 17 15
OmniClass TitleFluid Applied Waterproofing

Region availability

Europe	Asia
Austria	Türkiye
Belgium
Czech Republic
Denmark
Finland
France
Germany
Ireland
Italy
Luxembourg
Netherlands
Norway
Poland
Portugal
Romania
Russia
Slovakia
Spain
Sweden
Switzerland
United Kingdom
