Roof WP system (Hyb. Polyurea) - MasterSeal Roof 2113

Specification

Specification

• Application of one coat with minimum total minimum thickness of 2 mm of two-component, 100% solid content, hybrid polyurea waterproof membrane MasterSeal M 813 from Master Builders Solutions (or analogous). To apply the product, a two component heated, high pressure, proportioning spray equipment will be used. The system includes the application of primer according substrate and topcoat. Physical properties of the complete system: Capillary water absorption (EN 1062-3): max. 0.01 kg/m² · h0.5 Permeability to water vapour (EN ISO 7783-1; EN ISO 7783-2): Sd = 5 Permeability to carbon dioxide (EN 1062-6): Sd min. 2000 Crack bridging (EN 1062-7 A- Static): A5 (+23ºC) Impact resistance (EN ISO 6271-1): min. 4 Nm Resistance to spreading fire and radiant heat (EN 13501 part 5): BRoof (t2) on bituminous substrates

Technical specification

Technical specification

• Unique ref.MasterSeal_Roof_2113
• Collection setMasterSeal® - Master Builders Solutions
• CollectionLiquid-Applied Roof Waterproofing Deck Coatings
• TypeObject (single object)
• Date of publishing2020-07-24
• Edition number1

Links

Links

• Product urlhttps://www.master-builders-solutions.com/en-gb/functions-and-applications/waterproofing-and-sealing/hot-spray/roofing
• Installation instructionshttps://assets.master-builders-solutions.com/en-gb/masterseal_m_813.pdf
• Instruction videohttps://www.youtube.com/watch?v=fUgZKllV-1A
• Product certificationhttps://www.master-builders-solutions.com
• Technical descriptionhttps://assets.master-builders-solutions.com/en-gb/masterseal_roof_2113.pdf

Related

Related

• Material mainPolyurea
• Material secondaryPolyurethane

Classification

Classification

• BIMobject CategoryBuilding Materials - Waterproofing & Membranes
• Uniclass 2015 CodePr_35_31_68_64
• Uniclass 2015 DescriptionPolyurethane (PUR) waterproof coatings
• CSI MasterFormat 2014 Code07 14 14
• CSI MasterFormat 2014 TitleHot Fluid-Applied Polyurea Waterproofing
• OmniClass TitleFluid Applied Waterproofing
• OmniClass Number23-13 25 17 15
