60 Minute Fire Resistive Hurricane Rated Transom with 60 Minute Fire Resistive Hurricane Rated Single Doors

60 Minute Fire Resistive Hurricane Rated Transom with 60 Minute Fire Resistive Hurricane Rated Single Doors

60 Minute Fire Resistive Hurricane Rated Transom with 60 Minute Fire Resistive Hurricane Rated Single Doors

20 to 120 minute fire protective and resistive, hurricane rated, aluminum framing system.
Offered in standard and custom finishes including high performance fluoropolymer finishes by PPG, clear anodized, bronze anodized, black anodized, Decoral®, any species of wood veneer, ornamental metal, and more.
Now available with Texas Department of Insurance (TDI) approvals for Windows/Walls and Single/Pair Doors.
60 to 120 minute fire resistive, hurricane rated assemblies tested to ASTM E-119, which limits the temperature-rise to 250° F above ambient on the non-fire side.
Tested to TAS 201, Large Missile Impact, TAS 202 Air and Water Infiltration and TAS 203, Cyclic Wind Loading.
Capable of floor-to-floor and wall-to-wall glazing.

Technical specification

Unique ref.60_m_fire_resist_hurricane_rated_transom_w_60_m_fire_resist_hurricane_rated_single_doors
Product familyWalls
Product groupFire resistive
TypeObject (single object)
Date of publishing2017-05-12
Edition number1

Links

Product urlhttp://safti.com/gpx-hurricane/

Related

Material mainGlass
Material secondaryAluminium
Designed inUnited States
Manufactured inUnited States

Classification

BIMobject CategoryWalls - Other Walls
IFC classificationCurtain Wall
UNSPSC nameGlass curtainwalling
UNSPSC code30151806
Uniclass 2015 CodeSs_25_60_35_30
Uniclass 2015 DescriptionFire-resistant glazing systems
CSI MasterFormat 2014 Code08 41 13.13
CSI MasterFormat 2014 TitleFire-Rated Aluminum-Framed Entrances and Storefronts
OmniClass Number23-17 15 11 25
OmniClass TitleHeat Strengthened Glass
CSI UniFormat II CodeB20
CSI UniFormat II TitleEXTERIOR CLOSURE

Region availability

North America
United States
