ComfortLine Compact CA

ComfortLine Compact CA
- Wall-mounted compact distribution boards
- Large flange openings
- Simple snap-in technology for installation panels
- Secure 3-point door locking
- Plumb fastening through depth level compensation
- Earthing set for protection class I (earthed) available

The repertoire of communication and media devices in living and working environments is constantly growing, and residential, commercial and industrial buildings are increasingly connected.

Numerous useful features of the ComfortLine series, such as the increased flange size and the unique locking technology, support you in your daily business, making electrical installations quick and simple as well as prepared for any future requirement.

Tekniset tiedot

- Numerous options for cable entry at the top, bottom, sides and rear
- Sheet steel rear wall with cable entry options
- The door is easy to attach and detach thanks to the upper hinge pin
- Two mounting levels: rear mounting level for the installation of media panels, front mounting level for the installation of distribution board panels and the distribution panel system CombiLine N
- Generous wiring space for N/PE cables and tool-free assembly of the N/PE Quick-terminal
- DIN EN 61439-1/-2/-3
- Protection class: II, double insulated
- Degree of protection: IP44 (with standard door), IP30 (without door)
- Mechanical impact strength: IK07
- Rated current: ComfortLine compact CA up to 125 A
- Usage: Indoor, wall-mounting
Multi-Dimentions:
- Depth: 160 mm
- Width: 300/550/800/1050 mm
- Height: 500/650/800/950/1100/1250 mm

Tekniset tiedot

Yksilöity viitecomfortline-compact-ca
TyyppiObjekti (yksittäinen objekti)
Julkaisupäivä2022-09-02
Painoksen numero1
Korkeus (mm)500
Leveys (mm)300
Syvyys (mm)160

Linkit

Tuotteen urlhttps://new.abb.com/low-voltage/products/enclosures/Sub-distribution-boards/comfortline

Liittyviä

Ensisijainen materiaaliJauhepinnoitettu teräs
Toissijainen materiaaliMuovi

Luokitus

BIMobject-luokkaSähköosat - Jakelu
ETIM-koodiEG000023
ETIM-nimiDistribution boards
