AXOR Edge 3h rim m bath m CN chr
AXOR Edge 3h rim m bath m CN chr
    AXOR

    AXOR Edge 3h rim m bath m CN chr

    Google翻訳,
    AXOREdge3穴リムマウントバスミキサー
    仕様
    • Surfaces: - 46430007 Chrome - 46430137 Polished Bronze - 46430307 Polished Red Gold - 46430337 Polished Black Chrome - 46430997 Polished Gold Optic Specification: • consists of: 3-hole rim mounted single lever bath mixer, baton hand shower, shower holder • 2 functions • projection: 210 mm • spray type mixer: normal spray • spray type hand shower: Rain, Mono • maximum pull-out length of hand shower: 1.45 m • sBox for quiet, smooth and protected hose guidance • maximum flow rate at 3 bar: 19 l/min • flow rate for bath spout at 3 bar: 19 l/min • flow rate of hand shower at 3 bar: 8 l/min • ceramic cartridge • temperature limitation adjustable • non-return valve • suitable for continous flow water heaters • connection dimension: DN15 • connection type: basic set • min. operating pressure: 1 bar • max. operating pressure: 10 bar • removable for service at any time • no additional maintenance opening required
    技術仕様
    • 固有参照番号46430007
    • 製品ファミリAXOR Edge
    • 製品グループBath mixers
    • タイプオブジェクト(1つのオブジェクト)
    • 公開日2022-11-29
    • 版番号1
    関連
    • 設計国ドイツ
    • 製造国ドイツ
    • 正味重量(kg)8.3
    分類
    • BIMobjectカテゴリーサニタリー - 蛇口・混合栓
    • IFC分類バルブ
    • ETIM コードEC010862
    • ETIM 名称Bath mixing tap
    • UNSPSC 名称Sanitary ware
    • UNSPSC コード301815
    • Uniclass 2015 コードPr_40_20_76
    • Uniclass 2015 説明Sanitary accessories
    • CSI MasterFormat 2014 コード22 41 39
    • CSI MasterFormat 2014 タイトルResidential Faucets, Supplies, and Trim
    • OmniClass 番号23-31 11 00
    • OmniClass タイトルFaucets
    • CSI UniFormat II コードD2010
    • CSI UniFormat II タイトルPlumbing Fixtures

    対応地域

    アジア
    中華人民共和国
