AXOR Edge therm conc4o struc CN ch
AXOR Edge therm conc4o struc CN ch
    AXOR

    AXOR Edge therm conc4o struc CN ch

    Google翻訳,
    AXOREdgeサーモスタットモジュール4つの機能の隠し取り付けには610/100を選択-ダイヤモンドカット
    仕様
    • Surfaces: - 46721007 Chrome - 46721137 Polished Bronze - 46721307 Polished Red Gold - 46721337 Polished Black Chrome - 46721997 Polished Gold Optic Specification: • consists of: Thermostatic module, shower holder, baton hand shower • 4 functions • Select push-button on/off control for 4 outlets • simultaneous use of several outlets • thermostat cartridge, Start/stop valve to operate the functions • safety lock at 40 °C • temperature limitation adjustable • hose nut: for shower hoses with cylindrical nut on both sides • connection type: basic set • min. operating pressure: 1 bar • max. operating pressure: 10 bar • Thermostat is delivered with buttons hand shower, Waterfall, Rain large, Mono
    技術仕様
    • 固有参照番号46721007
    • 製品ファミリAXOR Edge
    • 製品グループShower thermostat
    • タイプオブジェクト(1つのオブジェクト)
    • 公開日2022-11-29
    • 版番号1
    関連
    • 設計国ドイツ
    • 製造国ドイツ
    • 正味重量(kg)8
    分類
    • BIMobjectカテゴリーサニタリー - シャワー
    • IFC分類サニタリーターミナル
    • ETIM コードEC011329
    • ETIM 名称Shower mixing tap
    • UNSPSC 名称Showers
    • UNSPSC コード30181503
    • Uniclass 2015 コードPr_40_20_87_76
    • Uniclass 2015 説明Shower heads
    • CSI MasterFormat 2014 コード22 41 23
    • CSI MasterFormat 2014 タイトルResidential Showers
    • OmniClass 番号23-31 17 00
    • OmniClass タイトルShowers
    • CSI UniFormat II コードD2010
    • CSI UniFormat II タイトルPlumbing Fixtures

    対応地域

    アジア
    中華人民共和国
