Powermite 599 MT Series Valve Assembly, Normally Closed, 1/2" Line Size, 0.4 to 2.5 Cv, FxF, Brass Trim, Electronic Actuator, Fail In-Place, Floating
Product Number: 259-02000
Description: This Powermite 599 MT Series Normally Closed Valve Assembly features an electronic actuator with 24 volts AC operating voltage, floating and Fail In-Place. The assembly is ANSI Leakage Class IV, has a brass trim and a female to female connection. This assembly has a flow rate of 0.4 Cv, and a line size of 1/2".
Product Number: 259-02002
Description: This Powermite 599 MT Series Normally Closed Valve Assembly features an electronic actuator with 24 volts AC operating voltage, floating and Fail In-Place. The assembly is ANSI Leakage Class IV, has a brass trim and a female to female connection. This assembly has a flow rate of 0.63 Cv, and a line size of 1/2".
Product Number: 259-02004
Description: This Powermite 599 MT Series Normally Closed Valve Assembly features an electronic actuator with 24 volts AC operating voltage, floating and Fail In-Place. The assembly is ANSI Leakage Class IV, has a brass trim and a female to female connection. This assembly has a flow rate of 1.0 Cv, and a line size of 1/2".
Product Number: 259-02006
Description: This Powermite 599 MT Series Normally Closed Valve Assembly features an electronic actuator with 24 volts AC operating voltage, floating and Fail In-Place. The assembly is ANSI Leakage Class IV, has a brass trim and a female to female connection. This assembly has a flow rate of 1.6 Cv, and a line size of 1/2".
Product Number: 259-02008
Description: This Powermite 599 MT Series Normally Closed Valve Assembly features an electronic actuator with 24 volts AC operating voltage, floating and Fail In-Place. The assembly is ANSI Leakage Class IV, has a brass trim and a female to female connection. This assembly has a flow rate of 2.5 Cv, and a line size of 1/2".
Feature
Standard actuator connection
Standard stroke - 5.5mm
Spring range built-in to valve (1/2" to 1" line sizes only) for pneumatic actuator
ANSI Class 250
2-way (NO, NC) and 3-way (Mix)
Choice of bronze (25 psi) or Stainless (50 psi) trim
O-ring type packing for chilled or hot water (35°F - 250°F) or steam (15psig)
Tight shut-off ANSI Class IV seat leakage (0.01% of Cv) with metal-to-metal seating
>100:1 Valve Rangeability
Choice of end connections
½" to 1" Line size, 0.4 to 10 Cv
Sample Applications
Description: This Powermite 599 MT Series Normally Closed Valve Assembly features an electronic actuator with 24 volts AC operating voltage, floating and Fail In-Place. The assembly is ANSI Leakage Class IV, has a brass trim and a female to female connection. This assembly has a flow rate of 0.4 Cv, and a line size of 1/2".
Product Number: 259-02002
Description: This Powermite 599 MT Series Normally Closed Valve Assembly features an electronic actuator with 24 volts AC operating voltage, floating and Fail In-Place. The assembly is ANSI Leakage Class IV, has a brass trim and a female to female connection. This assembly has a flow rate of 0.63 Cv, and a line size of 1/2".
Product Number: 259-02004
Description: This Powermite 599 MT Series Normally Closed Valve Assembly features an electronic actuator with 24 volts AC operating voltage, floating and Fail In-Place. The assembly is ANSI Leakage Class IV, has a brass trim and a female to female connection. This assembly has a flow rate of 1.0 Cv, and a line size of 1/2".
Product Number: 259-02006
Description: This Powermite 599 MT Series Normally Closed Valve Assembly features an electronic actuator with 24 volts AC operating voltage, floating and Fail In-Place. The assembly is ANSI Leakage Class IV, has a brass trim and a female to female connection. This assembly has a flow rate of 1.6 Cv, and a line size of 1/2".
Product Number: 259-02008
Description: This Powermite 599 MT Series Normally Closed Valve Assembly features an electronic actuator with 24 volts AC operating voltage, floating and Fail In-Place. The assembly is ANSI Leakage Class IV, has a brass trim and a female to female connection. This assembly has a flow rate of 2.5 Cv, and a line size of 1/2".
Feature
Standard actuator connection
Standard stroke - 5.5mm
Spring range built-in to valve (1/2" to 1" line sizes only) for pneumatic actuator
ANSI Class 250
2-way (NO, NC) and 3-way (Mix)
Choice of bronze (25 psi) or Stainless (50 psi) trim
O-ring type packing for chilled or hot water (35°F - 250°F) or steam (15psig)
Tight shut-off ANSI Class IV seat leakage (0.01% of Cv) with metal-to-metal seating
>100:1 Valve Rangeability
Choice of end connections
½" to 1" Line size, 0.4 to 10 Cv
Sample Applications
- Air handling units
- Terminal boxes
- Unit ventilators
- Baseboard heating
- VAV reheat coils
