CaptiveAire

Centrifugal Upblast Belt Drive Fan, NCA Series

Name: Centrifugal Upblast Belt Drive Fan, NCA Series
Rating: 4.1 (9 reviews)

4.1(9 評價)

Air Volume: 400 - 20000 cfm

Maximum SP: 2.75" wg. @ standard air density

FEATURES & BENEFITS

A wide variety of motors are available to meet specific application needs.

Heavy duty construction, durable and weather resistant.

Non-overloading backward inclined wheels, blades and inlets fabricated from 3003-H14 aluminum.

Wall mount applications, units up to 24" nominal wheel can be wall mounted.

Forced fresh air through the motor compartment cools motor and ensures long motor life.

Quick release latches allow for easy access to motor compartment.

Variable pitch motor pulley allows for field adjustment and system balancing.

High efficiency combined with low tip speeds result in quiet operation.

Standard emergency disconnect switch.

OPTIONS

Gravity Damper. (UL 705 Only)

Motorized Damper. (UL 705 Only)

Wall Mount Sleeve.

Roof Curb. (Vented & Non-Vented)

Grease Collection Box.

Bird Screen. (UL 705 Only)

Base Hinging Kit or Hinged Sub Base. (for NFPA96 compliance)

Extra Set of V-Belts

Combination package that includes a supply fan mounted on the same roof curb.

CERTIFICATIONS
CaptiveAire Systems, Inc. certifies that Models NCA08FA thru NCA36FA shown herein are licensed to bear the AMCA seal. The ratings shown are based on tests and procedures performed in accordance with AMCA Publication 211 and Publication 311, and comply with the requirements of the AMCA Certified Rating Program.

Models NCA08FA thru NCA36FA are ETL Listed under file numbers 3049729-001 and 3049729-002 and comply with UL705 (electrical) and UL762 Standards and CSA Std C22.2, No 113.

技術規格

唯一參考captiveaire-012
產品系列HVAC
產品組合Centrifugal Fans
類型对象（单个对象）
發佈日期2011-09-02
版本號1

連結

產品網址http://www.captiveaire.com/catalog/fanCatalog.asp?catid=104

相關

設計國家/地區美國
製造國家/地區美國

分類

BIMobject 類別暖通空调 - 空调
Uniclass 2015 代碼Ss_65_40_33_51
Uniclass 2015 說明Mechanical supply ventilation systems
CSI MasterFormat 2014 代碼23 00 00
CSI MasterFormat 2014 標題Heating, Ventilating, and Air Conditioning (HVAC)
OmniClass 編號23-33 00 00
OmniClass 標題HVAC Specific Products and Equipment
CSI UniFormat II 代碼D30
CSI UniFormat II 標題HVAC
