RainSelect Thermostat for concealed installation for 3 functions

规格

规格

• Surfaces: - 15381007 Chrome - 15381147 Brushed Bronze - 15381347 Brushed Black Chrome - 15381997 Polished Gold Optic - 15381707 Matt White - 15381677 Matt Black Specification: • 3 functions • depending on volume flow and installation situation approx. 50% flow rate reduction and integrated shut off function • Select push-button on/off control for 3 outlets • simultaneous use of several outlets • thermostat cartridge, Start/stop valve to operate the functions • safety lock at 40 °C • temperature limitation adjustable • non-return valve • connection type: basic set • min. operating pressure: 1 bar • max. operating pressure: 10 bar • Thermostat is delivered with buttons handshower, PowderRain, shoulder shower

技术规格

技术规格

• 唯一参考15381007
• 产品系列Shower thermostat
• 产品组RainSelect
• 类型对象（单个对象）
• 发布日期2022-11-23
• 版本号1

链接

链接

• 产品网址https://www.hansgrohe.com.cn/articledetail--15381007

相关

相关

• 主材料铬
• 设计国家/地区德国
• 制造国家/地区德国
• 净重 (Kg)4

分类

分类

• BIMobject 类别卫生 - 淋浴器
• IFC 分类卫浴终端
• ETIM 代码EC011329
• ETIM 名称Shower mixing tap
• UNSPSC 名称Showers
• UNSPSC 代码30181503
• Uniclass 2015 代码Pr_40_20_87_76
• Uniclass 2015 说明Shower heads
• CSI MasterFormat 2014 代码22 41 23
• CSI MasterFormat 2014 标题Residential Showers
• OmniClass 编号23-31 17 00
• OmniClass 标题Showers
• CSI UniFormat II 代码D2010
• CSI UniFormat II 标题Plumbing Fixtures
