S9000 Corner Window - Fixed Window - Fixed Window

The new GEALAN-System S9000 is an innovative window system for PVC-Windows and PVC-Doors with a construction depth of 82.5 mm. It combines the countless advantages of the central gasket and the overlap gasket. The large construction depth, six chamber profiles and three consistent sealing surfaces guarantee a outstanding thermal insulation.

With the Profile combination 6016 / 6003 you can build the window even more high-class by using the additional possibilities like static dry glazing (STV®), intensive core insulation (IKD®) or acrylcolor.

Keywords: Corner, Corner Window, Corner Windows, variable Corner Window

Specification
  • Corner Window Construction: Fixed Window - Fixed Window

    • Burglar-inhibiting window: RC1, RC2, RC2N

    • Construction depth: 82.5 mm

    • Iron mounting: concealed or visible

    Please notice: width and height of he element are depending on the construction type!

    Optional available with:

    • IKD® (intensive core insulation)

    • STV® (static dry glazing)

    • Acrylcolor

    • Foiled (uni-colours and wood decor)

    • Aluminium shell

    • Overlap gasket

    Realizable are:

    • Passive house windows

    • KfW-55 windows

    • KfW-70 windows

    • Fixed windows

    System complementary elements like doorsets or lift and slide doors are available.

Technical specification
  • Unique ref.S9000_CornerWindow_Fixed_Fixed
  • Collection setPVC Corner Window
  • CollectionS9000 Corner Window
  • TypeObject (single object)
  • Date of publishing2022-01-12
  • Edition number1
  • Depth (mm)82.5
Related
  • Material mainPVC
  • Material secondaryGlass
  • Designed inGermany
  • Manufactured inGermany
Classification
  • BIMobject CategoryWindows - Windows
  • IFC classificationWindow
  • UNSPSC nameWindows
  • UNSPSC code301716
  • Uniclass 1.4 CodeJL10
  • Uniclass 1.4 DescriptionWindows
  • Uniclass 2.0 CodeSS-10-50-25-25
  • Uniclass 2.0 DescriptionDoors, Windows And Glazing Survey Systems
  • Uniclass 2015 CodeEF_25_30
  • Uniclass 2015 DescriptionDoors and windows
  • NBS Reference Code59-97
  • NBS Reference DescriptionWindows
  • CSI MasterFormat 2014 Code08 50 00
  • CSI MasterFormat 2014 TitleWindows
  • OmniClass Number23-17 13 00
  • CSI UniFormat II CodeB2020
  • CSI UniFormat II TitleExterior Windows
