LVC Model 270-LF-STSTL - Point of Use Mixing Valve in a SS Cabinet

Unique ref.: 270-lf-ststl-rec
Brand: Leonard Valve Company
Product family: Mixing Valves for Liquid Services
Product group: Seventy Series - Point of Use Mixing Valves
Date of publishing: 2016-02-03
Edition number: 1
Type: Object (single object)
Download (2)
>1/2" NPT Inlet & Outlet Connections
>Minimum Flow = 0.25 gpm
>Maximum Flow = 12.0 gpm
>Temperature Adjustment Range, 90-140ºF
>Knob Handle with Locking Mechanism
>Approvals: ASSE 1070 & 1017
>Eco-Mix Certified Lead Free Construction
>Mounted in stainless steel cabinet with hinged door and cylinder lock


Material main:
Material secondary:
Designed in: United States
Manufactured in: United States

BIMobject Category: Plumbing - Valves
This product is available in:
North America
  • Canada
  • Mexico
  • United States

BIMobject SEEK Properties

Plumbing - Valves

Name Value
Connection Type Compression

Leonard Valve Company

Properties

Name Value
Minimum Flow Rate 0.25 GPM
Connection Size of Outlet 1/2"
Connection Size of Inlets 1/2"
Weight 10 lbs
Cabinet Dimensions 10"W x 10"H x 5"D
Maximum Flow Rate 12 GPM
Valve and Assembly Dimensions 5"W x 5-1/2"H
Valve Body Material Cast Bronze
Cabinet Mounting Recessed | Surface
Valve Finish Rough Bronze | Chrome Plated
Cabinet Material Stainless Steel
Cabinet Yes
