Three-arm turnstile

Revolutionary design, won German Design Award 2018 Extensive functions and intuitive operation Drop-arm mechanism (optional) permits passage during power outages or alarms Ethernet plug-in module for IP connection (optional) Designed for 10,000,000 opening and closing cycles

Specification

Control and drive system: - Integrated control system with display for parameterization and set-up - MHTM drive system for minimum 10 million opening and closing cycles - Connection for 100 – 240 VAC, 50/60 Hz - Connections for all current card reader systems - 8 digital inputs with free allocable functions - 4 digital outputs and 6 output relays for illumination control and status readout (free allocable) Housing material: - 2 component-polyurethane mDure - Highly resistant to impacts, scratches and abrasion - Resistant against corrosion, UV light, detergents and disinfectants - Environmentally friendly disposal as household garbage - Enclosure protection rating: IP54 Dimensions: - Dimensions of housing: 730 x 1050 x 290 mm (W x H x D) - Passage width: 515 mm - Installation space for readers: 60 x 80 x 40 mm (W x H x D) Installation: - Screw mounting on stable floor surface - Alternative mounting on unfinished floor by use of adjustable foundation frame - Alternative glue mounting by use of a metal base plate - Temperature range: -30 to +50 °C Options & Accessories: - Customer-specific colour versions - LED frame illumination in Green/Red - LED floor illumination in White - Drop-Arm for power outage or in case of alarm (self-restoring) - Passage indicator Green/Red (Gate end display GED) - Mechanical locking unit - Over-climb detection - Under-crawl detection - Buzzer - Signalization LED - Ethernet interface - Foundation mounting frame - Attachement set - Emergency push buttion - Guiding rail system mGuide

Technical specification

Unique ref.magnetic-mTripod-short
Collection setFlowMotion
CollectionPedestrian gates
TypeObject (single object)
Date of publishing2018-09-16
Edition number1
Height (mm)1050
Width (mm)730
Depth (mm)805

Links

Product urlhttps://www.magnetic-access.com/en/products/pedestrian-gates/flowmotion/mtripod.html
Instruction videohttps://vimeo.com/680903305
Product certificationhttps://www.magnetic-access.com/en/downloads/certificates.html
Technical descriptionhttps://www.magnetic-access.com/files/downloads/Datenblaetter/Personensperren/Zutrittskontrolle-FlowMotion/58070045EN.pdf

Material main2C Polyurethane
Material secondaryMetal
Weight Net (Kg)57

Classification

BIMobject CategoryDoors - Doors
IFC classificationFurniture
Uniclass 2015 CodeAc_20_85_63
Uniclass 2015 DescriptionPedestrian security checking
CSI MasterFormat 2014 Code11 14 13
CSI MasterFormat 2014 TitlePedestrian Gates
