Supply grille of horizontal-vertical double deflection with air flow regulation incorporated_RTHV

Unique ref.: AirQ_RTHV_CFX
Brand: Airzone
Product family: AirQ
Product group: Air Grille
Date of publishing: 2017-11-17
Edition number: 1
Type: Object (single object)
Download (3)
Extruded aluminum grille supply. 26-mm standard frame. Horizontal and vertical moving slats for an individual regulation as they adapt the air range and the air stream to the needs of the zone. Integrated flow regulation damper, manually operable by screw.

Lengths available from 200 to 800 mm . Compatible accesories : Plenum for grilles (PREJ)


Material main: Aluminium
Material secondary:
Designed in: Spain
Manufactured in: Spain

BIMobject Category: HVAC - Ductwork
IFC classification: Distribution Control Element
UNSPSC name: Air diffusers
UNSPSC code: 40101505
Uniclass 1.4 Code: JU30
Uniclass 1.4 Description: Air conditioning systems
Uniclass 2.0 Code: SS-65-80
Uniclass 2.0 Description: Air Conditioning Systems
Uniclass 2015 Code: Ss_65_80
Uniclass 2015 Description: Air conditioning systems
NBS Reference Code: 65-80
NBS Reference Description: Air Conditioning Systems
CSI MasterFormat 2014 Code: 23 09 33
CSI MasterFormat 2014 Title: Electric and Electronic Control System for HVAC
OmniClass Number: 23-33 49 00
OmniClass Title: HVAC Ductwork
CSI UniFormat II Code: D3090
CSI UniFormat II Title: Other HVAC Systems & Equipment
