Swing Door Operator DAB105

Swing Door Operator DAB105

Swing Door Operator DAB105

Archived

Swing Door Operator DAB105

Ditec DAB105 is an electromechanical servo-assisted automation system for swing doors with spring, with 24 Vdc gear motor and encoder-managed kinematics, for safe and reliable management of door movement in every situation. The silent operation and clean, elegant look make Ditec DAB105 the preferred choice for swing doors in the commercial and public sector applications. The powerful gear motor easily moves wings up to 200 kg of weight or over 1.2 m of width. Ditec DAB105 can work in both push or pull mode with dedicated arms connecting the opener to the door panel. The numerous operation modes (Low Energy, PUSH&GO, Power Assist, sensor control, push-button control, etc.), as well as the possibility to easily manage double-wing swing opening make Ditec DAB105 an ideal solution that easily adapts to any requirement. A wide choice of accessories and control devices completes the product range. Ditec DAB105 fully complies with all European directives including EN 16005.

Technical specification

Unique ref.dit-dab105
Product familyAutomatic Doors
Product groupSwing Doors by Ditec
TypeObject (single object)
Date of publishing2020-09-23
Edition number1
Height (mm)111
Width (mm)720
Depth (mm)131

Links

Product urlhttps://www.ditecautomations.com/en/products/automatic-pedestrian-doors/swing-doors/ditec-dab105
Installation instructionshttps://www.ditecautomations.com/en/products/automatic-pedestrian-doors/swing-doors/ditec-dab105
Technical descriptionhttps://www.ditecautomations.com/en/products/automatic-pedestrian-doors/swing-doors/ditec-dab105

Related

Material mainAluminium
Material secondarySteel
Designed inItaly
Manufactured inChina
Weight Net (Kg)13.9

Classification

BIMobject CategoryDoors - Openers
IFC classificationObject
UNSPSC nameDoor openers
UNSPSC code30171512
Uniclass 2015 CodePr_75_30_23_09
Uniclass 2015 DescriptionAutomatic swing-door operators
