LAPITEC FAÇADE ADAPTIVE PANELS
LAPITEC FAÇADE ADAPTIVE PANELS
LAPITEC FAÇADE ADAPTIVE PANELS

LAPITEC FAÇADE ADAPTIVE PANELS

Unique ref.: LAPITEC-FACADE-ADAPTIVE-PANELS
Brand: Lapitec
Product family: Lapitec for ventilated facade
Product group: Sintered stone slabs
Date of publishing: 2019-10-02
Edition number: 1
Type: Object (single object)
Download (4)
Lapitec® is a sintered stone, an innovative material produced in the form of a large size slab using an exclusive patented technology, which can be applied both indoors and outdoors. Lapitec® sintered stone is resistant to wear, atmospheric agents, exposure to sunlight (UV), heat, frost and water absorption.
The different surface finishes of Lapitec® make it suitable for use both for floors and walls. (see classification according standards DIN 51130, DIN 51097, UNI EN 14231)
Lapitec® is compatible with a wide range of adhesives and fixing systems that allow it to be installed on various types of supports and substrates; it can be used without limitations in different situations, even particularly harsh ones (humid environments, saline atmospheres, presence of aggressive pollutants etc.).

Lapitec slabs are suitable for facade application, with different fixing systems, mechanical and in adhesion. All systems have been studied in terms of structural resistances and are certified by Lapitec in partnership with each producer.

LAPITEC H1 (in partnership with KEIL BEFESTIGUNGSTECHNIK GmbH)
KEIL mechanical fixing system

LAPITEC H2 (in partnership with FISCHER ITALIA Srl)
FISCHER mechanical fixing system

LAPITEC V (in partnership with SFS INTEC)
Rivet mechanical fixing system
Upon request, should be provided rivets thermoacquered in the same colour as Lapitec slabs.

LAPITEC B (in partnership with DOW CORNING and SIKA)
Adhesive systems require close collaboration with the manufacturers of the adhesive and absolute compliance with the instructions they provide.


Technical specifications for the fixings are provided in the tables in the dedicated section of the Technical Facades Manual available on https://www.lapitec.com/download/manuals and more design details at https://www.lapitec.com/download/design


Material main: Sintered stone
Material secondary:
Designed in: Italy
Manufactured in: Italy

BIMobject Category: Walls - Cladding
UNSPSC name: Tiles and flagstones
UNSPSC code: 301317
Uniclass 1.4 Code: JH6
Uniclass 1.4 Description: Slate/Tile cladding/covering
Uniclass 2015 Code: Ss_25_20
Uniclass 2015 Description: Wall cladding systems
NBS Reference Code: 25-20
NBS Reference Description: Wall Cladding Systems
This product is available in:
Asia
  • Armenia
  • Azerbaijan
  • Bangladesh
  • Bhutan
  • British Indian Ocean Territory
  • Brunei
  • Cambodia
  • China
  • Christmas Island
  • Cocos (Keeling) Islands
  • Georgia
  • Hong Kong
  • India
  • Indonesia
  • Japan
  • Kazakhstan
  • Kyrgyzstan
  • Laos
  • Macau
  • Malaysia
  • Maldives
  • Mongolia
  • Myanmar (Burma)
  • Nepal
  • North Korea
  • Pakistan
  • Philippines
  • Singapore
  • South Korea
  • Sri Lanka
  • Taiwan
  • Tajikistan
  • Thailand
  • Turkmenistan
  • Uzbekistan
  • Vietnam
Europe
  • Åland Islands
  • Albania
  • Andorra
  • Austria
  • Belarus
  • Belgium
  • Bosnia and Herzegovina
  • Bulgaria
  • Croatia
  • Cyprus
  • Czech Republic
  • Denmark
  • Estonia
  • Faroe Islands
  • Finland
  • France
  • Germany
  • Gibraltar
  • Greece
  • Guernsey
  • Hungary
  • Iceland
  • Ireland
  • Isle of Man
  • Italy
  • Jersey
  • Latvia
  • Liechtenstein
  • Lithuania
  • Luxembourg
  • Macedonia (FYROM)
  • Malta
  • Moldova
  • Monaco
  • Montenegro
  • Netherlands
  • Norway
  • Poland
  • Portugal
  • Romania
  • Russia
  • San Marino
  • Serbia
  • Slovakia
  • Slovenia
  • Spain
  • Svalbard and Jan Mayen
  • Sweden
  • Switzerland
  • Ukraine
  • United Kingdom
  • Vatican City
North America
  • Anguilla
  • Antigua and Barbuda
  • Aruba
  • Barbados
  • Belize
  • Bermuda
  • British Virgin Islands
  • Canada
  • Caribbean Netherlands
  • Cayman Islands
  • Collectivity of Saint Martin
  • Costa Rica
  • Cuba
  • Curaçao
  • Dominica
  • Dominican Republic
  • El Salvador
  • Greenland
  • Grenada
  • Guadeloupe
  • Guatemala
  • Haiti
  • Honduras
  • Jamaica
  • Martinique
  • Mexico
  • Montserrat
  • Nicaragua
  • Panama
  • Puerto Rico
  • Saint Kitts and Nevis
  • Saint Lucia
  • Saint Pierre and Miquelon
  • Saint Vincent and the Grenadines
  • Saint-Barthélemy
  • Sint Maarten
  • The Bahamas
  • Trinidad and Tobago
  • Turks and Caicos Islands
  • U.S. Virgin Islands
  • United States
South America
  • Argentina
  • Bolivia
  • Brazil
  • Chile
  • Colombia
  • Ecuador
  • Falkland Islands (Islas Malvinas)
  • French Guiana
  • Guyana
  • Paraguay
  • Peru
  • Suriname
  • Uruguay
  • Venezuela

BIMobject SEEK Properties

Walls - Cladding

Name Value
Depth 12 | 20 | 30
Height 0 mm — 3365 mm
Width 0 mm — 1500 mm
