ENTRA® Field-Adjustable Entry Light

The redesigned ENTRA puts lighting control at your fingertips with three selectable wattages and CCTs in one fixture. Easily adjust settings to create the perfect ambiance for your entryway, walkway, or corridor with just one single SKU. ENTRA features a vandal-resistant polycarbonate housing and lens that stand up to impact while maintaining a clean, contemporary appearance. It also has an IP65 rating that protects it against dust and water.

The integrated on/off photocell automatically activates your lighting at dusk and turns it off at dawn, saving energy without sacrificing
safety. This set-it-and-forget-it feature ensures your entryways are properly illuminated when needed.

KEY FEATURES

Field-adjustable entry light with selectable wattages: 14/11/7W (Default 14W)
Adjustable CCT: 3000/4000/5000K (Default 4000K)
Driver: 120–277V with 0-10V dimming (dims to off)
Comes with selectable on/off photocell (Default off)
Suitable for wet locations
IP65 rated
Vandal resistant
ADA compliant for wall-mounted luminaires
100,000-hour LED lifespan
5-year limited warranty

Specification

Compliance
- UL Listed; suitable for wet locations
- IP65 rated for dust and water ingress protection
- ADA compliant for wall-mounted luminaires
- Trade Agreements Act compliant (product of Cambodia, designated country end product)
- IESNA LM-79 and LM-80 tested by independent laboratory
LED Characteristics
- Long-life, high-efficacy, surface-mount LEDs
- 100,000-hour lifespan based on IES LM-80 results and TM-21 calculations
- Color uniformity per ANSI C78.377-2017
- CRI: 84 at 3000K and 5000K; 86 at 4000K (all wattages)
Construction
- Wall mount
- Die-cast aluminum housing
- Frosted polycarbonate lens
- Silicone gaskets
- Aluminum reflector with high-reflectance white finish
- Minimum starting temperature: -40°F (-40°C)
- Maximum ambient temperature: 104°F (40°C)
- BUG Rating: B0-U3-G2
- Mercury and UV free; RoHS-compliant components
- High-durability, long-lasting color finish; available in bronze or white
Field Adjustable Settings
- Wattage: 14/11/7W (14W default)
- Color temperature: 3000/4000/5000K (4000K default)
- Photocell: On/Off (Off default)
Electrical
- Driver: Constant Current, Class 1, 120–277V, 50/60 Hz
- 0–10V dimming; dims down to off (requires separate 0–10V DC dimming circuit)
- Surge protection: 2kV L-L and 2kV L/N-G
- Integrated on/off photocell included
- THD at 4000K:
  - 14W: 5.46% at 120V / 10.99% at 277V
  - 11W: 4.79% at 120V / 16.23% at 277V
  - 7W: 11.63% at 120V / 24.93% at 277V
- Power Factor:
  - 14W: 99.5% at 120V / 94.5% at 277V
  - 11W: 99.6% at 120V / 91.1% at 277V
  - 7W: 98.4% at 120V / 82.9% at 277V
- Amperage draw:
  - 14W: 120V: 0.12A, 208V: 0.07A, 240V: 0.06A, 277V: 0.05A
  - 11W: 120V: 0.10A, 208V: 0.06A, 240V: 0.05A, 277V: 0.04A
  - 7W: 120V: 0.06A, 208V: 0.04A, 240V: 0.04A, 277V: 0.03A
Warranty
- 5-year limited warranty covering light output, driver performance, and paint finish
