Envelope 2000® Metal Composite Material (MCM)

Code Tested:

• Panel
• ASTM E84 (Flame Spread)
• ASTM D1781 (Peel Strength)
• ASTM D1929 (Ignition Temperature)
• ASTM D51929 (Impact Resistance)


Panel Composition: 10 -Year Panel Warranty

• 024″ Smooth Aluminum
• .105″ Thermoset Phenolic Resin
• .010″ Primed Aluminum

Panel Thickness: 4mm (nominal)

• Thermoset phenolic resin core provides an ultra-smooth substrate.

Panel Weight: 1.25 lb./sq. ft. (nominal)

Standard Sizes:

• 48″ x 96″ (121.9cm x 243.8cm)
• 48″ x 120″ (121.9cm x 304.8cm)
• 48″ x 144″ (121.9cm x 365.8cm)
• 60″ x 96″ (152.4cm x 243.8cm)
• 60″ x 120″ (152.4cm x 304.8cm)
• 60″ x 144″ (152.4cm x 365.8cm)

Finishes/Finish Warranty:

• Kynar 500® Finish: 30 Years (Pre-finished standard colors/coil-coated)
• Kynar 500® Finish: 20 Years (Custom colors spray-applied)
• Anodized Finish: 20 Years

Recycled Content by Weight:

Lead Time:

• Available nationwide, these panels can be found locally or shipped to customer.

Other Features:

• Cut to Size: These panels can be easily cut to the correct dimension on site using standard tools.
• Curveable: Along with various shadow lines, add interest with long sweeping curves or tight, crisp column covers.
• Low Maintenance: Most matter can be cleaned from surface with mild detergents.
