No-Burn® Plus - Passive Fire Protective Coating

No-Burn® Plus - Passive Fire Protective Coating

No-Burn® Plus is a white, water-based thin film intumescent coating when exposed to high temperatures and flame, intumesces creating a char-barrier protecting treated Substrates from fire. Certified to be applied to a variety of Substrates, fire performance compliance is achieved with the appropriate wet film thickness.

PRIMARY USES:

For use in new and existing buildings, complying with the IBC®, IRC® IEBC® and other applicable codes or standards, Plus is utilized in applications where it provides:

  • Surface Burning Characteristics
  • Interior Finish Classification Class I or Class A:
    • Flame Spread (FS) 0-5
    • Smoke Developed (SD) 0-35
  • Alternative or Non-prescriptive Thermal Barrier Protection
  • Fire Resistance
  • Class III Vapor Retardancy
規格
  • SPECIFICATIONS:

    • Color: Opaque/White/Tinted
    • Finish: Flat
    • VOC Content: 18 g/L EPA Method 24
    • Dry Time: 60-90 Minutes
    • Pails: 5 Gallons (19 L), 55 lbs.
    • Drums: 55 Gallons (208 L), 605 lbs.
    • Shelf Life: 24 Months
    • Cure Time: 24 Hours
    • Boiling Point: 212°F
    • Freezing Point: 32°F
    • % Volatile by Volume: 38%
    • Specific Gravity: 1.25

    APPLICABLE STANDARDS:
    No-Burn® Plus may be specified in compliance of the following:

    • AC14 CARB
    • AC257 CDPH (CA Spec 01350)
    • AC377 CHPS
    • ANSI/ASHRAE/ICC/USGBC Standard 189.1 CSFM: 2280-2014:0100
    • ANSI/NSF 51 EC017
    • ASTM A653 GSA PBS-P100
    • ASTM D2915 ICC/ASHRAE 700 NGBS
    • ASTM D5055 IgCC
    • ASTM E84 LEED v3 2009
    • ASTM E84, 30 min LEED v4
    • ASTM E96 NFPA 255
    • ASTM E119 NFPA 286
    • ASTM E1623 SCAQMD Rule 1113
    • ASTM E2768 UL 723
    • CAN/ULC-S102 UL 1715
技術規格
  • 唯一參考no-burn-plus-passive-fire-protective-coating
  • 產品系列Building Insulation
  • 產品組合Spray Foam Insulation
  • 類型对象(单个对象)
  • 發佈日期2026-07-15
  • 版本號1
相關
  • 主材料聚氨酯
  • 設計國家/地區美國
  • 製造國家/地區美國
分類
  • BIMobject 類別建筑材料 - 隔离
  • CSI MasterFormat 2014 代碼07 21 19
  • CSI MasterFormat 2014 標題Foamed-In-Place Insulation
  • OmniClass 編號23-13 25 19
  • OmniClass 標題Thermal Insulation
