INDOOR UNIT DUCTED WITH MEDIUM HEAD FOR INSTALLATION IN FALSE CEILING, FOR VRF SYSTEM WITH VARIABLE REFRIGERANT FLOW RATE R-410A
Multi-row direct expansion coil with aluminium finned copper tubes.
N° 2 refrigerant fluid filters on liquid and gas side in order to preserve the functioning of the electronic expansion valve and reduce noise.
Fan with single-phase three-speed induction motor and low absorption with electrical protection by means of thermal switch.
Possibility to adjust in 7 steps the static pressure of the fan.
Washable and regenerative synthetic fibre filter.
Condensate drain pump already included in the machine: head 850 mm
Pre-cut hole for fresh air inlet.
In the event of a power failure of the machine, the system will continue to operate
and indicates the error.
- Available sizes: 0.8, 1, 1.25, 1.7, 2, 2.5, 3, 3.2, 4, 5, 6 HP (from 2.2 to 16,0 kW)
- Compact design: height only 275 mm
- Low sound level
- Equipped with drain pump
- A vary large filter selection could be used
- Inlet for outside air
