Trimoterm Sandwich Panel

Trimoterm is a range of environmentally friendly fireproof and insulated walls. Ideal for those who need high-quality fire resistance and thermal insulation.

Opis

Name
Trimoterm FTV, Trimoterm FTV HL

Joint type
Visible (FTV), hidden (FTV HL)

Description
Fire-resistant sandwich panel for external walls, partitions, ceilings and flat roofs with a non-combustible mineral wool core.

Product name	Trimoterm FTV
Manufacturer	Trimo
Use	External walls, internal walls, ceilings and flat roofs
Panel thickness (mm)	50 - 250
Panel width (mm)	600 - 1200
Panel length (mm)	2000 - 14000
Insulation core	Mineral wool, Non-combustible, Class A1
Insulation core density	90 - 120 kg/m3
Max. achievable fire resistance (EN 14509)	EI 30 - EI 240
Reaction to fire	A2-s1, d0
Thermal transmittance (W/m2 K)	0,75 - 0,15
Coating	SP or PVDF or PUR/PA
External facing - profile	S, V, V2, G, M, M3, M8
Internal facing - profile	S, V, V2, G, M, M2
Water permeability (Pa - wall)	Class A (1200 Pa)
*Air permeability (C (m3 /Pas);n)**	C = 0.00005; n = 1.5
Water vapour permeability	Impermeable
Airborne sound insulation: Rw(C:Ctr)	up to 32 (-2,-4) (dB)
