BIGFOOT® FLEXY LINEAR INTERIOR

PROTEK BIGFOOT® FLEXY INTERIOR

100% metal extruded pocket frame in extruded aluminum model BIGFOOT® FLEXY INTERIOR, made of vertical uprights with tubular section interlocking on the bottom and lid in aluminum; uprights in anodized aluminum to ensure high resistance to oxidation and adhesion of the wall paintings, vertical uprights including fastening system for coating with rigid panels (e.g. wainscoting) suitable for obtaining different panel mounting solutions at the request of the client, appropriate screws included.

Predisposition for sliding guide on the ground, normally equipped with shock-absorbing system in closing. Telescopic anti-tipping guide on the upper part of the pocket frame.

Made in standardized dimensions for internal walls covered with rigid structure panels (ST) of 135/185/330 mm, also suitable for installation on movable walls, next to existing walls, as a backdrop for separating rooms or as a curtain, in as it is equipped with fixing systems that allow installation without drilling the floor. Nominal standardized dimensions from (L) 600 to 1500 mm and (H) from 2100 to 2400 mm. Counter frame designed for installation without jambs and architraves; conceived to facilitate any electrical connections, with motor that can be installed even when the installation is complete, can be supplied in a kit to be assembled or, on request already assembled, suitable for housing inside a retractable sliding container module on the floor guide, made in wood / aluminum, of the type, finish and functionality chosen by the customer.

The internal sliding module can be replaced at any time with another of equal or smaller dimensions, with the same or different functionality and finish.

Doorway dimensions: L mm ………………. X H mm .................. X ST mm ..................
