Beam
| Unique ref.: | beam |
|---|---|
| Brand: | StarTek Lighting |
| Product family: | Beam Series Lighting |
| Product group: | Beam |
| Date of publishing: | 2020-04-12 |
| Edition number: | 1 |
| Type: | Object (single object) |
Downloads
Direct
- Continuous lens option available – up to 200’
- Extruded aluminum single piece housing
- 4’ and 8’ individual units, or continuous rows
- Straight runs with proprietary joiner design
- Efficacy up to 150 lm/W
- Soft diffuse direct lighting
- Textured powder coat finishes available in white, black, silver and bronze
- Premium finishes also available
- Approved for dry and damp locations
- 0-10v dimming is standard
- Dim to 1% of output current
Direct/Indirect
- Extruded Aluminum housing
- 2’ x 2’ and 4’ x 4’ options available
- Efficacy up to 135 lm/w
- Soft diffuse direct lighting
- Direct and Indirect light levels can be set to any combination at the factory
- Textured powder coat finishes available in white, black, silver and bronze
- Premium finishes also available
- Approved for damp and dry locations
- 0-10v dimming is standard
- Dim to 1% of output current
Housing
Nominal 3 1/2” x 3 1/2” square housing of continuous extruded 6063 T5 aluminum.
Color
Colors for the housing are available in a powder coated white, black, silver, bronze and woodgrain with end cap to match. Consult factory for custom colors.
Luminaire Length
4' or 8' lengths are available for a single stand-alone section. Using internal joiners, 4’ and 8’ sections can be joined to form longer rows.
End Caps
Injection molded flat end caps are mechanically attached with no exposed fasteners to enhance architectural aesthetic and prevent light leak (woodgrain is standard in metal).
Source
Two standard lumen packages are available in four color temperature options (3000K, 3500K, 4000K and 5000K) — all within 2.5 MacAdam ellipses.
Certification
Intertek cETLus Listed. DLC Premium listed options are available. RoHS (Restriction of Hazardous Substances) and Made in USA.
Battery
Philips Bodine lithium ion battery providing up to 780lm(6W) or up to 1300lm(10W) for 90 minutes. UL924 listed. Class 2 compliant. Meets Title 20 CEC (California Energy Commission) efficiency standards.
Environment
Suitable for dry and damp locations. Operating temp.: -40°C to +50°C -40°F to +122°F
Dimming Driver
Universal Lighting Technologies (ULT) Everline series of LED drivers allows tunable output currents to achieve infinite configurations of output. UL Class 2 recognized. 0-10v interface can be wired as Class 1 or Class 2 circuit. Included 2.5Kw ring and wave overcurrent protection, isolation of each individual output and a fully potted driver to protect from heat and vibration. Power factor <.93
Packaging
Sustainably manufactured outside cardboard box and biodegradable, protective poly-foam luminaire inserts.
| Product url: | https://starteklightingamerica.com/beam/ |
|---|---|
| Installation instructions: | |
| COBie Product Data Sheet: | |
| Product certification: | |
| Technical description: | https://starteklightingamerica.com/beam/ |
| Instruction video: | |
| GTIN code: |
The Qr code includes the static URL below and will bring you back to this page if scanned by a device like iPhone or smartphone
https://www.bimobject.com/en-us/startek-lighting/product/beam
| Material main: | Aluminium |
|---|---|
| Material secondary: | |
| Designed in: | United States |
| Manufactured in: | United States |
| BIMobject Category: | Lighting - Ceiling Mounted |
|---|---|
| IFC classification: | Light Fixture |
| UNSPSC name: | Lighting Fixtures and Accessories |
| UNSPSC code: | 3911 |
| Uniclass 1.4 Code: | JV5 |
| Uniclass 1.4 Description: | General lighting |
| Uniclass 2.0 Code: | EE-70-50-80 |
| Uniclass 2.0 Description: | Building Lighting |
| Uniclass 2015 Code: | EF_70_80 |
| Uniclass 2015 Description: | Lighting |
| NBS Reference Code: | 70-50-80 |
| NBS Reference Description: | Building Lighting |
| CSI MasterFormat 2014 Code: | 26 51 00 |
| CSI MasterFormat 2014 Title: | Interior Lighting |
| OmniClass Number: | 23-35 47 11 |
| OmniClass Title: | Lighting Fixtures |
| CSI UniFormat II Code: | D5020 |
| CSI UniFormat II Title: | Lighting & Branch Wiring |
